Vibrotor Dual Roller Vibrator

Brand Martin
Series DVR
Model DVR-5500
Item # 14156
Quantity

Overview

Martin's Vibrotor CCR vibrator is a rotary pneumatic vibrator designed to prevent build-up or blockage of bulk solids in hoppers, bins, railcars, chutes, molds, and screens . It's unique design generates multiple vibrations on each orbit, providing high-frequency vibration. The Vibrotor CCR is affordable, eliminates wear problems, and can be portable or mounted. Mount options include weldable cradle lug bracket, cradle lug wedge bracket, cradle lug clamp mount, or cradle lug bolt mount. The Vibrotor CCR vibrator is available in single and dual-roller options.

Specifications

Force Lbs @ 40 PSI 3582
Force Lbs. @ 60 PSI 5596
Force Lbs @ 80 PSI 7020
VPM @ 40 PSI 1000
VPM @ 60 PSI 12500
VPM @ 80 PSI 14000
CFM @ 40 PSI 42
CFM @ 60 PSI 55
CFM @ 80 PSI 58
Unbalance (in-lbs) 1.262
Weight 53.3 lbs

Dimensions

A: 10

B: 7.37

C: 6.5

D: 4 holes 2.76 x 7.87

E: 5.5

F: 4.13

G: 0.75

H: 0.69

K: 0.5
